IMPACT 1040

This is a discontinued product.

Overview

For large projects that require large nozzle sizes or more than one spray gun in a single device, you can rely on the power and performance of the Impact® 1040. This powerhouse is perfect for large residential, commercial and industrial properties where speed and performance are essential to get the job done faster and more efficiently.







Key Features:



• High Flow Capacity: Designed to consistently spray 300-400 gallons per week, accommodating substantial project demands.
• Advanced Packing System: Equipped with Quad+ Packings™, which effectively wipe abrasive coatings clean during operation, preventing damage to the piston and main sealing lip.
• Automatic Lubrication: Features AutoOiler™ technology, allowing users to deliver oil directly to the packings with the push of a button, ensuring optimal performance and longevity.
• Electronic Pressure Control: Includes Electronic Pressure Control with Rapid Clean, expediting the flushing and cleaning process for enhanced efficiency.
• Durable Construction: The PermaLife™ Cylinder is designed to never wear and never need replacing, contributing to the sprayer’s long-term reliability.

Specifications



• Max. Delivery 1.15 | 4.36
• Max operating pressure 3300 psi | 22.8 MPa
• Max Tip Size – 1 Gun – Electric 0.033″
• Max Tip Size – 2 Guns – Electric 0.022″
• Motor 2.5 HP DuraLife Brushless HE
• Recommended Gallons Per Week 300-400
• Items Included RX-Pro Gun, 517 Tip, 1/4″ x 50′ Airless Hose

Applications



Ideal for coatings like stains, lacquers, enamels, latex, and epoxies, this sprayer is built to handle demanding tasks with high efficiency.







Configurations



• Part Number 552600: Impact 1040 High Rider – Weight 98 lbs.
• Part Number 2453769: Impact 1040 Low Rider – Weight 95 lbs.

Key Feature

• Designed to consistently spray 200-500 gallons per week

• Quad+ Packings™ are designed to remove abrasive coatings during operation, preventing damage to the piston or main sealing lip

• AutoOiler™ allows you to push a button to deliver oil from the reservoir directly to the packings

• Electronic Pressure Control with Rapid Clean speeds up the flushing and clean-up process

• PermaLife™ Cylinder never wears and never needs replacing

• Fast removal fluid section, designed with a T-slot piston and simple clamped upper housing makes removal fast

Technical Specifications

Product Specific Specs IMPACT 1040, HR, COMP, 120V

Holder / Mount	High Rider
Certification	Complies with cETLus directive

Common Specifications Impact 1040

Max. Tip (“)	0.033 “
Max. Operating Pressure (psi)	3300 psi
Max. Material Delivery Rate (gal/min)	1.15 gal/min
Weight (lbs)	98 lbs
Package Contents	RX-Pro gun, TR1 517 Nozzle, 1/4″ x 50′ (15m) Airless Hose

Download

Service manual – Parts list

User manual
