C.A. Technologies 5-Gallon Top Outlet Pressure Tanks

Top Outlet Pressure Tanks

Overview

C.A. Technologies offers a 2.5-gallon pressure tank designed for various industrial applications. Constructed from heavy-gauge steel with a baked-on enamel finish, this tank ensures durability and reliability. For applications involving water-borne or corrosive coatings, a SS version is available, fabricated entirely from 304 SS, including the tank lid, shell, pickup tube, fluid outlets, and all wetted parts. Features:Capacity: 2.5 gallonsConstruction: Heavy-gauge steel with baked-on enamel; SS option for corrosive materialsDimensions: Diameter of 10.5 inches and depth of 8.75 inchesPressure Rating: Maximum of 80 psi (15 psi when used with solvents)Design: Flat bottom to accommodate 1-quart and 1-gallon cans; equipped with wheels for easy maneuverabilityConfigurations: Available with Sgl or dual regulators, and with or without air agitatorsFor resin casting applications, C.A. Technologies offers a specialized version (Model 51-201C). This model features a top outlet design, a Sgl air pressure regulator, and omits the pickup tube and fluid outlet fittings to suit casting needs.  C.A. Technologies offers a variety of configurations for 2.5-gallon pressure tanks to accommodate diverse industrial applications. Select Part Number Below to overview of the available models
