Binks Quick Cleaner

Binks Quick Cleaner Simple Design for Effortless Cleaning

Overview

Reduces solvent consumption during flush sequences by 30% – 50% Reduce equipment flush times by 20%-60%.

The new Quick Cleaner will help you to reduce your waste disposal costs and lower your VOC output. Flush times are lowered, decreasing color change times and improving overall process efficiency.

Key Feature

• Simultaneously mixes solvents and compressed air to scrub paint lines and passages reducing solvent usage and cleaning time.
• Eliminates potential color contamination
• Infinite adjustability allows for the proper solvent-air ratio to ensure clean fluid passages
• All wetted parts are stainless steel, PTFE and plated brass to work with all materials and solvents
• Check valves on both air and fluid inlets prevent possible backflow contamination
• Fit and forget; no wear parts requiring regular maintenance
• Easily installed with multiple mounting methods
•  Connectable to either NPSM or BSP threads

Specifications

• Maximum Inlet Working  Pressure (Air/Fluid): 6.9 Bar (100 psi, 10.69 MPa)
• Fluid Passage Materials: Stainless Steel PTFE Nickel Plated Brass
• Inlet Threads Compatible With: 1/4 BSP, 1/4 NPSM
• Outlet Threads Compatible With: 3/8 BSP, 3/8 NPSM
• Part Number:  HD-QCH-500
